Application:
Suitable for dust removal and ventilation equipment in the ceramic industry, woodworking industry, industrial vacuum cleaners, etc. (such as suction and exhaust: fine particles, wood chips, fiber debris, oil vapor, welding smoke).
Product features:
The product has strong wear resistance, weather resistance, tear resistance, high transparency, light weight, flexible bending, non-toxic, odorless, halogen-free, etc.
Temperature range:
-40℃ to +90℃ (up to +125℃ for short-term use).
| I.D MM | THICKNESS MM | OPERATING PRESSURE BAR | VACUUM PRESSURE BAR | LENGTH M |
| 25 | 0.60 | 1.600 | 0.360 | 10 15 |
| 30 | 0.60 | 1.500 | 0.340 | 10 15 |
| 32 | 0.60 | 1.260 | 0.340 | 10 15 |
| 38 | 0.60 | 1.060 | 0.320 | 10 15 |
| 40 | 0.60 | 1.015 | 0.300 | 10 15 |
| 50 | 0.60 | 0.815 | 0.260 | 10 20 |
| 60 | 0.60 | 0.680 | 0.210 | 10 20 |
| 64 | 0.60 | 0.630 | 0.180 | 10 20 |
| 70 | 0.60 | 0.585 | 0.150 | 10 20 |
| 75 | 0.60 | 0.545 | 0.140 | 10 20 |
| 80 | 0.60 | 0.510 | 0.130 | 10 20 |
| 90 | 0.60 | 0.455 | 0.115 | 10 20 |
| 100 | 0.60 | 0.410 | 0.090 | 10 20 |
| 110 | 0.60 | 0.375 | 0.080 | 10 20 |
| 115 | 0.60 | 0.355 | 0.080 | 10 20 |
| 120 | 0.60 | 0.340 | 0.075 | 10 20 |
| 125 | 0.60 | 0.330 | 0.060 | 10 20 |
| 130 | 0.60 | 0.315 | 0.060 | 10 20 |
| 140 | 0.60 | 0.295 | 0.060 | 10 20 |
| 150 | 0.60 | 0.275 | 0.055 | 10 20 |
| 160 | 0.60 | 0.255 | 0.050 | 10 20 |
| 170 | 0.60 | 0.240 | 0.045 | 10 20 |
| 175 | 0.60 | 0.235 | 0.040 | 10 20 |
| 180 | 0.60 | 0.230 | 0.040 | 10 20 |
| 200 | 0.60 | 0.205 | 0.038 | 10 20 |
| 210 | 0.60 | 0.190 | 0.035 | 10 20 |
| 220 | 0.60 | 0.185 | 0.032 | 10 |
| 225 | 0.60 | 0.180 | 0.030 | 10 |
| 250 | 0.60 | 0.165 | 0.025 | 10 |
| 275 | 0.60 | 0.150 | 0.020 | 10 |
| 300 | 0.60 | 0.135 | 0.015 | 10 |
| 325 | 0.60 | 0.130 | 0.010 | 10 |
| 350 | 0.60 | 0.115 | 0.010 | 10 |
| 375 | 0.60 | 0.100 | 0.010 | 10 |
| 400 | 0.60 | 0.080 | 0.010 | 10 |
