Inner Tube: SBR blended,black and smooth
Reinforcement:Textile braided high tensile synthetic yarn
Cover: EPDM/SBR blended,black,yellow or red, smooth weather and ozone,abrasion resistant
Application:
Abrasion resistant, weather resistant and zone resistant. Its of pressure bearable, flexible, light in weight, anti-bending, less distortion and nice smooth surface. This rubber water pipe is suitable for use with air tools, air compressors, and air guns. It is designed for irrigation and can convey water at normal temperatures, as well as general neutral liquids in mining, factories, agriculture, and civil engineering construction.
Temperature Range:-30°C To +80°C (-22°F To +176°F)
ID | WP | BP | Bending Radius | Weight | Length | ||||
mm | inch | Mpa | bar | Mpa | bar | mm | B | kg/m | m |
6 | 1/4" | 3 | 30 | 9 | 90 | 80 | 1 | 0.17 | 20-50 |
8 | 5/16" | 3 | 30 | 9 | 90 | 100 | 1 | 0.25 | 20-50 |
10 | 3/8" | 3 | 30 | 9 | 90 | 130 | 1 | 0.3 | 20-50 |
12.5 | 1/2" | 3 | 30 | 9 | 90 | 180 | 1 | 0.46 | 20-50 |
16 | 5/8" | 2.5 | 25 | 7.5 | 75 | 210 | 1 | 0.53 | 20-50 |
19 | 3/4" | 2.5 | 25 | 7.5 | 75 | 240 | 1 | 0.6 | 20-50 |
22 | 7/8" | 2 | 20 | 6 | 60 | 280 | 1 | 0.8 | 20-50 |
25 | 1" | 2 | 20 | 6 | 60 | 375 | 1 | 0.93 | 20-50 |
32 | 1-1/4" | 1.5 | 15 | 4.5 | 45 | 420 | 2 | 1.25 | 20-50 |
38 | 1-1/2" | 1.5 | 15 | 4.5 | 45 | 500 | 2 | 1.47 | 20-50 |
45 | 1-3/4" | 1.2 | 12 | 3.6 | 36 | 630 | 2 | 1.76 | 20-50 |
50 | 2" | 1.2 | 12 | 3.6 | 36 | 630 | 2 | 1.92 | 20-50 |
57 | 2-1/4" | 1 | 10 | 3 | 30 | 855 | 2 | 2.1 | 20-50 |
64 | 2-1/2" | 1 | 10 | 3 | 30 | 960 | 2 | 2.56 | 20-50 |
76 | 3" | 0.8 | 8 | 2.4 | 24 | 1140 | 2 | 2.96 | 20-50 |
90 | 3-1/2" | 0.6 | 6 | 1.8 | 18 | 1350 | 2 | 3.7 | 20-50 |
100 | 4" | 0.6 | 6 | 1.8 | 18 | 1530 | 2 | 4.3 | 20-50 |
