Characteristics: soft, elastic, bright and billant
Apply to: industry and agriculture
PART # | Nominal Diameter | ID | OD | Length | WP | BP | WEIGHT | Packing Size D×H |
inch | mm | mm | m | bar | bar | kg/roll | mm | |
3 PVC & 2 Braided Layers Series | ||||||||
PVCSPRHP07 | 1/4 | 7 | 13 | 100 | 50 | 160 | 13 | 450 x 130 |
PVCSPRHP08 | 5/16 | 8 | 14 | 100 | 50 | 160 | 14 | 500 x 140 |
PVCSPRHP10 | 3/8 | 10 | 16 | 100 | 50 | 150 | 16.5 | 520 x 140 |
PVCSPRHP13 | 1/2 | 13 | 20 | 100 | 40 | 130 | 24.5 | 560 x 190 |
2 PVC & 1 Braided Layers Series | ||||||||
PVCSPR 06122 | 1/4 | 6 | 12.2 | 100 | 30 | 100 | 11 | 400 x 135 |
PVCSPR 06135 | 1/4 | 6 | 13.5 | 100 | 30 | 100 | 13.5 | 400 x 145 |
PVCSPR 06512 | 1/4 | 6.5 | 12 | 100 | 30 | 100 | 10.6 | 400 x 130 |
PVCSPR 07513 | 9/32 | 7.5 | 13 | 100 | 30 | 100 | 11.8 | 450 x 130 |
PVCSPR 08514 | 5/16 | 8.5 | 14 | 100 | 30 | 100 | 13 | 500 x 140 |
PVCSPR 1016 | 3/8 | 10 | 16 | 100 | 30 | 100 | 16.4 | 520 x 140 |
PVCSPR 1320 | 1/2 | 13 | 20 | 100 | 25 | 80 | 24.3 | 560 x 190 |
