SAE 100 R13

Hose Construction:
Inner tube: oil resistant synthetic rubber
Reinforcement: four or six high tensile steel wire spiral
Cover: oil, abrasion, weather resistant synthetic rubber
Working Temp.: -40℃ up to +121℃
Applications:
Very high pressure applications subject to surge or flexing such as construction equipments, mining and the high performance industrial market

Inside Diameter		Reinforcement Diameter	Outside Diameter	WP		BP		Min. Bend Radius	Weight
inch	mm	mm	mm	psi	bar	PSI	bar	mm	kg/m
3/4	18.6-19.8	29.2-29.8	32.0-32.8	5075	350	20300	1400	240	1.65
1	25.0-26.4	35.5-36.1	38.3-39.1	5075	350	20300	1400	300	2.25
1-1/4	31.4-33.0	47.1-47.7	49.9-50.7	5075	350	20300	1400	420	3.6
1-1/2	37.7-39.3	54.7-55.3	57.5-58.3	5075	350	20300	1400	500	4.75
2	50.4-52.0	67.7-68.3	71.5-72.3	5075	350	20300	1400	630	6.9
