Smooth Surface PVC Suction Hose

Smooth Surface PVC Suction Hose

Surface: smooth
Application: For suction and delivery of liquids, powder, granules in industry, agriculture and construction.
  • Smooth Surface PVC Suction Hose
  • Smooth Surface PVC Suction Hose
Features:
Flexible PVCsuction pipe with rigid PVC spiral reinforcement, abrasion and chemical resistant, impact and crush resistant, smooth inner construction for unrestricted flow of materials.
Temperature Range :-5℃ to +65℃

Specification of Smooth Surface PVC Suction Hose

PART#

SIZE

I.D.

O.D.

LENGTH

MAX.W.P (BAR)

MAX. B.P (BAR)

WEIGHT


INCH

MM

MM

M/ROLL

AT 23℃

G/M

PVCSUC02-1923

3/4"

19

23

30

6

18

230

PVCSUC02-2529

1"

25

29

30

6

18

290

PVCSUC02-3236

1-1/4"

32

36

30

6

18

350

PVCSUC02-3238

1-1/4"

32

38

30

6

18

400

PVCSUC02-3844

1-1/2"

38

44

30

6

18

550

PVCSUC02-3846

1-1/2"

38

46

30

6

18

650

PVCSUC02-5054

2"

50

54

30

5

15

550

PVCSUC02-5056

2"

50

56

30

5

15

700

PVCSUC02-6369

2-1/2"

63

69

30

4

12

880

PVCSUC02-6371

2-1/2"

63

71

30

4

12

1170

PVCSUC02-7581

3"

75

81

30

3

9

1160

PVCSUC02-7583

3"

75

83

30

3

9

1300

PVCSUC02-100108

4"

100

108

30

3

9

1950

PVCSUC02-100110

4"

100

110

30

3

9

2300

PVCSUC02-125135

5"

125

135

20

3

9

3000

PVCSUC02-125137

5"

125

137

20

3

9

3300

PVCSUC02-152164

6"

152

164

10

2

6

4500

PVCSUC02-152166

6"

152

166

10

2

6

5500

PVCSUC02-200214

8"

200

214

10

2

6

6300
