Heavy Duty PVC Nitrile Layflat Hose
BEST IN CLASS RUBBER HOSE

Heavy Duty PVC Nitrile Layflat Hose

Heavy Duty PVC Nitrile Layflat Hose
  • Heavy Duty PVC Nitrile Layflat Hose
Reinforcement: Circular woven polyester jacket
Operating Temperature Range: From -20℉ to 178℉ (-29℃ to 81℃)
Standard Color: Yellow or black, other colors available per request
Standard Length: 50ft, 100ft, 300ft/91.5m, 330ft/100m, other lengths available per request
Our heavy duty PVC/Nitrile layflat hose  is produced in  one step, through-the –weave construction.  Its high working pressure is due to high-strength polyester filament. The excellent durability benefits from a high-tensile PVC/NBR compound. The ribs on the outer cover increase abrasion resistance.

Heavy duty PVC/Nitrile layflat hose is widely used in agricultural irrigation, mining dewatering, industrial and construction washdown, water transfer for many lines.
Inner tube and cover: PVC/Nitrile
The ribs on the cover surface greatly help to provide a long service life.

Specification of Heavy Duty PVC Nitrile Layflat Hose

SIZE

MM

W.P.(PSI)

B.P.(PSI)

1"

25

300

900

1 1/2"

40

300

900

1 3/4"

45

300

900

2"

52

300

900

2 1/2"

65

300

900

3"

76

300

900

4"

102

200

600

5"

127

200

600

6"

156

200

600

8"

204

200

600

10"

254

200

600
