SAE 100 R16

Hose Construction:
Inner tube: oil resistant synthetic rubber
Reinforcement: two high tensile steel wire braid
Cover: oil and weather resistant synthetic rubber
Working Temp.: -40℃ up to +100℃
Applications:
High pressure hydraulic applications and to replace 100R1 where higher pressure and a more flexible hose is required.

Hose ID		W.D.	O.D	W.P		B.P		Min.B.R.	WEIGHT
INCH	MM	MM	MM	BAR	PSI	BAR	PSI	MM	KG/M
1/4	6.4	11.3	13.4	345	5000	1380	20000	50	0.27
5/16	7.9	12.8	15	293	4250	1172	17000	55	0.35
3/8	9.5	15.1	17.4	275	3990	1100	15960	65	0.42
1/2	12.7	18.3	20.6	240	3500	960	14000	90	0.52
5/8	15.9	21.7	23.8	190	2760	760	11040	105	0.63
3/4	19	25.5	27.8	155	2250	620	9000	125	0.81
1	25.4	32.8	35.9	138	2000	552	8000	150	1.17
